Features
- Sony Exmor back-illuminated CMOS sensor with USB3.0 interface
- Real-time 8/12/14/16bit depth switch (depending on sensor)
- Super high sensitivity up to 1120mV (IMX185)
- Super low noise and low power dissipation
- With advance Video & image processing application Micaps MicroView
Applications
- Scientific research, education (teaching, demonstration and academic exchanges)
- Digital laboratory, medical research
- Industrial visual (PCB examination, IC quality control)
- Medical treatment (pathological observation)
- Food (microbial colony observation and counting)
- Aerospace, military (high sophisticated weapons)
| Order Code | Sensor & Size(mm) | Pixel(μm) | G Sensitivity Dark Signal | FPS/Resolution | Binning | Exposure |
|---|---|---|---|---|---|---|
| HPE3CMOS02300CB | 2.36M/IMX185(C) 1/1.9”(7.2X4.5) | 3.75 x 3.75 | 1120mv with 1/30s 0.5mv with 1/30s |
45@1920×1200 90@960×600 |
1×1 2×2 |
0.244ms ~ 2000ms |
| Software Environment Under Lan/wan/usb Video Output | |
|---|---|
| Spectral Range | 380-650nm (with IR-cut Filter) |
| White Balance | ROI White Balance / Manual Temp-Tint Adjustment |
| Color Technique | Super Fine Color Engine |
| Capture/Control SDK | Windows/Linux/macOS/Android Multiple Platform SDK (Native C/C++, C#/VB.NET, Python, Java, DirectShow, Twain, etc) |
| Recording System | Still Picture and Movie |
| Data Format | MJPEG |
| Cooling System* | Natural |
| Operating System | Microsoft® Windows® XP / Vista / 7 / 8 / 8.1 / 10 (32 & 64 bit), OSx (Mac OS X), LINUX |
| PC Requirements | CPU: Equal to Intel Core2 2.8GHz or Higher, Memory: 2GB or More, USB port: USB2.0 High-speed port, Display: 17″ or Larger, CD-ROM |
| OPERATING ENVIRONMENT | |
|---|---|
| Operating Temperature (in Centidegree) | -10° ~ 50° |
| Storage Temperature (in Centidegree) | -20° ~ 60° |
| Operating Humidity | 30 ~ 80%RH |
| Storage Humidity | 10 ~ 60%RH |
| Power Supply | DC 5V over PC USB port |
| Model Name | Download PDF |
| HPF3CMOS02300CB |  Download |
