Features
- Standard C-Mount camera with Sony Starvis (Back illuminated) CMOS sensor
- Rolling Shutter
- CNC aluminum alloy housing
- USB2.0 interface ensuring high speed data transmission
- Ultra-Fine color engine with perfect color reproduction capability
- With advanced video & image processing application MicroView
- Windows/Linux/macOS/Android multiple platform SDK
Applications
- Digital laboratory, medical research
- Industrial visual (PCB examination, IC quality control)
- Medical treatment (pathological observation)
- Food (microbial colony observation and counting)
- Aerospace, military (high sophisticated weapons)
- Scientific research, education (teaching, demonstration and academic exchanges)
| Order Code | Sensor & Size(mm) | Pixel(μm) | G Sensitivity Dark Signal | FPS/Resolution | Binning | Exposure |
|---|---|---|---|---|---|---|
| HPSCMOS8300CA | 8.3M/IMX274(C) 1/2.5″(6.22×3.50) | 1.62×1.62 | 236mv with 1/30s 0.1mv with 1/30s | 4@3840×2160 16@1920×1080 | 1×1 2×2 |
0.244ms~15s |
| HPSCMOS6600CA | 6.6M/IMX326(C) 1/2.9″(4.98×3.50) | 1.62×1.62 | 236mv with 1/30s 0.1mv with 1/30s | 5@3072×2160 6@2592×1944 6@3072×1728 7@2160×2160 | 1×1 1×1 1×1 1×1 |
0.244ms~15s |
| HPSCMOS5300CA | 5.3M/IMX178(C) 1/1.9″(7.37×4.15) | 2.4×2.4 | 425mv with 1/30s 0.15mv with 1/30s | 5.5@3072×1728 35@1280×720 | 1×1 1×2 |
0.105ms~15s |
| HPSCMOS5000CA | 5.0M/IMX335(C) 1/2.8″(5.18×3.89) | 2.0×2.0 | 505mv with 1/30s 0.13mv with 1/30s | 6.4@2592×1944 26.7@1296×972 | 1×1 2×2 |
0.1ms~15s |
| HPSCMOS3100CA | 3.1M/IMX123(C) 1/2.8″(5.12×3.84) | 2.5×2.5 | 600mv with 1/30s 0.15mv with 1/30s | 11.5@2048×1536 18.3@1920×1080 18.1@1600×1200 29.5@1024×768 | 1×1 1×1 1×1 2×2 |
0.105ms~15s |
| HPSCMOS2000CA | 2.0M/IMX290(C) 1/2.8″(5.56×3.13) | 2.9×2.9 | 1300mv with 1/30s 0.15mv with 1/30s | 17@1920×1080 | 1×1 | 0.105ms~15s |
| HPSCMOS1200CA | 1.2M/IMX224(C) 1/3″(4.80×3.60) | 3.75×3.75 | 2040mv with 1/30s 0.15mv with 1/30s | 27@1280×960 54@640×480 | 1×1 2×2 |
0.105ms~15s |
| Other Hardware Configuration | |
|---|---|
| Spectral Range | 380~650nm (with IR-filter), for Monochromatic Camera, AR is Used |
| White Balance | ROI White Balance/ Manual Temp-Tint Adjustment |
| Color Rendering Technique | Super Fine Color Engine |
| Capture/Control SDK | Windows/Linux/macOS/Android Multiple Platform SDK (Native C/C++, C#/VB.NET, Python, Java, DirectShow, Twain, etc) |
| ADC | 8 Bit |
| Recording System | Still Picture and Movie |
| Cooling System | Natural |
| Software Environment | |
|---|---|
| Operating System | Support Microsoft Windows XP / Vista / 7 / 8 / 10 (32 & 64 bit) OS X (Mac OS X), Linux |
| PC Requirements | CPU: Equal to Intel Core2 2.8GHz or Higher |
| Memory: 2GB or More | |
| USB port: USB2.0 High-speed Port | |
| Display: 17″ or Larger | |
| CD-ROM | |
| Operating Environment | |
|---|---|
| Operating Temperature | -10°C ~ 50°C |
| Storage Temperature | -20°C ~ 60°C |
| Operating Humidity | 30~80%RH |
| Storage Humidity | 10~60%RH |
| Power Supply | DC 5V over PC USB Port |
